GeoDuct - DN75 HDPE Corrugated Double Wall Cable Duct (50m Coil) (Solid)

R1,229

We supply GeoDuct - DN75 HDPE Corrugated Double Wall Cable Duct (50m Coil) (Solid). Send us your quantity and delivery location for a quotation, and ask our team to include installation where your project requires it.

GeoDuct DN75 is a solid-wall HDPE cable duct for routing and protecting underground electrical and communication cables. Its corrugated outer wall provides structure, while the smooth inner bore assists cable installation. Supplied in 50 m coils for utility networks, developments and civil works.

Request a quote or specification check

Include the product name, quantity and delivery location. Supply, fabrication and installation can be quoted to your scope.

Need help selecting the right grade? View the product selection guide →

SKU: GD-DN75-50C-SOLID Category: Drainage Pipes and Sheets Tags: Africa, Corrugated HDPE Pipes, GeoDuct, Geosynthetics Africa, HDPE Cable Duct, South Africa

Description

GeoDuct - DN75 HDPE Corrugated Double Wall Cable Duct (50m Coil) (Solid) is engineered for underground infrastructure across South Africa and Africa. With a corrugated outer wall for ring stiffness and a smooth inner bore for cable pulling / water conveyance, it delivers reliable performance on civil, mining and municipal projects. Geosynthetics South Africa is the region’s leading supplier of corrugated HDPE pipes.

Specifications

Outer Diameter (OD): 75 mm ±1
Inner Diameter (ID): 61 mm ±1
Bending Radius: 250 mm
Supply Length: 50 m
Compression Strength: >450 N (Normal Duty)
Standards: SANS 61386-24, EN 50086-2-4, EN ISO 9969
Resistance: Chemical & impact resistant

Applications

Telecom, fibre and electrical cable ducting networks
Underground conduit systems
Renewable energy cable routing
Mining & civil infrastructure

Supplier: Geosynthetics South Africa - South Africa & Africa’s leading supplier of corrugated HDPE pipes.

Supply, delivery and installation across Africa

Geosynthetics South Africa undertakes projects through three service options:

Supply only - products supplied to the agreed specification.
Supply and delivery - materials and logistics coordinated to your project site.
Supply, delivery and QA/QC-controlled installation - one coordinated scope from procurement to documented handover.

For projects across Africa, we coordinate with the Geosynthetics Africa Group to mobilise installation crews from group companies across the continent. Materials, delivery, mobilisation and project-specific quality records are agreed as part of the project scope.

Discuss your supply or installation project | Explore our product range

Technical Specifications

Size (DN)	DN75
Length/Coil	50 m Coil
Pipe Type	Solid
Material	HDPE Double Wall Corrugated
Compliance	SANS 61386-24; EN 50086-2-4; EN ISO 9969

Supply, delivery & installation

South African supply

We are the South African supplier of GeoDuct HDPE cable ducting. We have ready stock of standard grades and formats for South African projects.

Delivery & cross-border supply

We supply GeoDuct HDPE cable ducting across South Africa and Southern Africa, including cross-border delivery. We coordinate site access, unloading and cross-border documentation for your order.

How we install

We install GeoDuct HDPE cable ducting. Check the trench, bedding and cover requirements against the service design. Lay and couple the ducts, fit draw wire and cap open ends. Verify alignment and duct continuity before placing and compacting the specified backfill.

Specialist installation supported by Geosynthetics Africa (Pty) Ltd, an IAGI Installer Member.

Get a supply, delivery & installation quote

Product documents

Ask for the current datasheet and installation instructions for GeoDuct - DN75 HDPE Corrugated Double Wall Cable Duct (50m Coil) (Solid). Identify the catalogue grade / SKU in your request so the technical submission matches the material quoted.

Technical datasheets · Installation guides

Request documents for this grade

Engineer specification

Supply and install GeoDuct - DN75 HDPE Corrugated Double Wall Cable Duct (50m Coil) (Solid). Solid, double-wall corrugated HDPE cable duct; normal-duty impact classification N to SANS 61386-24; compression resistance ≥250 N at 5% inside-diameter deformation; diameter and supply format as named. Installed by an IAGI Installer Member.

SELECTION · SPECIFICATION · PROJECT SUPPLY

Choose the right specification

Select a complete drainage route from collection through the material to a suitable outlet.

Confirm whether the duty is drainage, leak detection, cable protection or structured-wall conveyance.
Specify dimensions, loading, flow conditions, interfaces and the exact filter arrangement where needed.
Coordinate connections, outlets, access and long-term performance for the actual application.

Define the quality records

Verify product identity, dimensional and relevant mechanical or hydraulic data, connections, filters and damage checks before covering.

For a useful quotation: send the grade or performance specification, quantity, location, required date and scope. Availability, delivery and installation responsibilities are confirmed in the quotation.

Why Geosynthetics South Africa

One enquiry coordinates the specified product, technical submission, delivery and any agreed installation and QA/QC scope. We define quantities, programme, responsibilities and handover requirements against your project.
