GSE HDPE Smooth Geoliner (1.00mm thick - 7m x 220m Roll)
Request a quote
We supply GSE HDPE Smooth Geoliner (1.00mm thick - 7m x 220m Roll). Send us your quantity and delivery location for a quotation, and ask our team to include installation where your project requires it.
GSE smooth HDPE geomembrane is a 1.0 mm water-containment liner for engineered dams, reservoirs, mining and waste-containment systems. It forms a low-permeability barrier between stored liquids and the underlying ground. Supplied in 7 m x 220 m rolls for welded lining installations.
Include the product name, quantity and delivery location. Supply, fabrication and installation can be quoted to your scope.
Need help selecting the right grade? View the product selection guide →
Description
GSE smooth HDPE geomembrane - 1.00 mm
This smooth high-density polyethylene geomembrane is supplied for welded lining installations in engineered containment systems. Product thickness, chemical compatibility, protection layers, terminations and installation details must suit the stored liquid, subgrade, operating conditions and approved design.
Current supplied roll format
| Item | Listed format |
|---|---|
| Nominal thickness | 1.00 mm |
| Roll width | 7 m |
| Roll length | 220 m |
| Nominal area per roll | 1,540 m² |
Allow for seam overlaps, anchor trenches, terminations and cutting waste when estimating the order quantity. The nominal roll area is not the net installed coverage.
Specification and technical documentation
Use the current technical data and conformity documents for the exact supplied grade. Check the required tensile, puncture, tear, stress-crack resistance and durability properties against the project specification. Suitability for a particular mining, waste, reservoir or pond application requires design approval; the application name alone does not establish that 1.00 mm is the correct thickness.
The linked manufacturer technical data sheet remains the reference for material properties. Its stated roll format may differ from the current supplied 7 m × 220 m format confirmed for this catalogue item.
Supply, delivery and installation
Geosynthetics South Africa coordinates product supply, delivery and specialist installation across South Africa and Southern Africa, supported by our parent, Geosynthetics Africa, and group companies for wider African projects. Installation and QA/QC requirements are defined for the agreed scope.
Request a quote or specification check | Explore related product systems
Technical Specifications
| Material | |
|---|---|
| Spec |
Supply, delivery & installation
South African supply
We are the South African supplier of GEOLINE HDPE geomembrane liners. We have ready stock of standard grades and formats for South African projects.
Delivery & cross-border supply
We supply GEOLINE HDPE geomembrane liners across South Africa and Southern Africa, including cross-border delivery. Roll handling, weather protection and site unloading are coordinated with your delivery.
How we install
We install GEOLINE HDPE geomembrane liners. Inspect and accept the smooth, prepared subgrade and install protection layers where specified. Deploy panels to the lining plan, weld seams and complete anchorage and penetrations. Test the seams and record repairs and final acceptance before the liner enters service.
Specialist installation supported by Geosynthetics Africa (Pty) Ltd, an IAGI Installer Member.
Get a supply, delivery & installation quoteProduct documents
Ask for the current datasheet and installation instructions for GSE HDPE Smooth Geoliner (1.00mm thick - 7m x 220m Roll). Identify the catalogue grade / SKU in your request so the technical submission matches the material quoted.
Technical datasheets · Installation guides
Request documents for this gradeEngineer specification
Supply and install GSE HDPE Smooth Geoliner (1.00mm thick - 7m x 220m Roll), manufactured by Solmax (GSE). 100% virgin HDPE, smooth finish, GRI-GM13; Thickness: 1.00 mm (ASTM D5199); Tensile Strength at Yield: 15 kN/m (ASTM D6693); Puncture resistance: 320 N (ASTM D4833); Stress crack resistance: ≥ 500 hr (ASTM D5397). Installed by an IAGI Installer Member.
SELECTION · SPECIFICATION · PROJECT SUPPLY
Choose the right specification
Containment is selected around the stored liquid, ground conditions, exposure and required barrier system.
- Confirm polymer, thickness, surface finish and the actual operating temperature and chemistry.
- Review the subgrade, protection layers, anchorage, penetrations and joining method.
- Use the current supplied-grade datasheet and project acceptance criteria, with material and installation records.
Define the quality records
Specify roll and batch traceability, material acceptance, joint inspections and appropriate tests for the selected liner system.
For a useful quotation: send the grade or performance specification, quantity, location, required date and scope. Availability, delivery and installation responsibilities are confirmed in the quotation.
Why Geosynthetics South Africa
One enquiry coordinates the specified product, technical submission, delivery and any agreed installation and QA/QC scope. We define quantities, programme, responsibilities and handover requirements against your project.
