MIRAFI® P30 – 300gsm Liner Protection Geotextile (6m x 120m Roll)
- ASQUAL-certified 300gsm nonwoven polypropylene geotextile
- Designed for HDPE geomembrane liner protection
- High puncture resistance (CBR 3.5 kN) and reliable filtration
- Roll size: 6m x 120m (720 m²)
Description
MIRAFI® P30 is a 300gsm continuous-filament, needle-punched, nonwoven polypropylene geotextile engineered for liner protection of GSE HDPE geomembranes in mining, waste, water and infrastructure projects across Africa. Geosynthetics Africa stocks and delivers across the continent with expert technical support.
Why choose Bidim P30 for liner protection?
- Lightweight cushioning with robust puncture resistance (CBR 3.5 kN)
- Excellent filtration/separation to protect the liner and maintain subgrade stability
- ASQUAL-certified quality and consistent performance
- Ideal under/over 1.0–2.5mm HDPE liners in dams, tailings, and landfills
Key specifications: 300 g/m²; thickness 3.0 mm; tensile strength 21 kN/m (MD/CMD); CBR puncture 3.5 kN; roll 6 m x 120 m (720 m²).
Technical Specifications
| Mass per unit area (gsm) | 300 |
|---|---|
| Roll width (m) | 6 |
| Roll length (m) | 120 |
| Area per roll (m²) | 720 |
| Thickness at 2 kPa (mm) | 3.0 |
| Tensile strength (kN/m) | 21 (MD/CMD) |
| CBR puncture (kN) | 3.5 |
