HDPE Pond Lining – Mazista Sewer Treatment Plant, South Africa
HDPE geomembrane lining installed for maturation and facultative wastewater treatment ponds at the Mazista Sewer Treatment Plant in South Africa.
Mazista Sewer Treatment Dams & Steel Tank Rehabilitation
Client: Bojanala Platinum District Municipality
Location: Swartdam, South Africa
Delivered By: Geosynthetics Africa — IAGI Installer Member
Scope: Lining of 3 Wastewater Ponds + Restoration of 3 Steel Tanks
Project Overview
The Bojanala Platinum District Municipality expanded wastewater treatment capacity by constructing three new process ponds. Geosynthetics Africa was appointed as the sole specialist liner contractor to execute the full containment system — from subgrade inspection to welding, QA/QC testing and final handover.
The new ponds required a durable, fully compliant barrier system to protect groundwater and ensure long-term environmental safety. In addition, three existing corrugated steel tanks required internal rehabilitation and sealing using EPDM lining.
Scope of Work Delivered
✔ Surface inspection & subgrade acceptance
✔ Installation of MIRAFI® Virgin PP Geotextile protection layer
✔ Installation of GRI-GM13 HDPE Geomembrane Lining
✔ 2:1 slope welding and secure anchor trench termination
✔ Pipe penetration detailing — 250mm Ø HDPE inlet/outlet
✔ Engineered gas venting system across all ponds
✔ Restoration of 3 corrugated steel tanks using EPDM Buffel Liner
✔ Aluminium batten strips + neoprene gaskets for secure perimeter sealing
✔ Full QA/QC — Vacuum Box, Air Pressure, Shear/Peel, Holiday Testing
✔ Local community labour & skills training
Ponds Lined
| Pond | Official Name | Dimensions | Retention Time | Function |
|---|---|---|---|---|
| Pond 1 | Maturation Pond 1 | 70m × 20m × 2m | ± 5 Days | Final polishing stage |
| Pond 2 | Facultative Pond 1 | 70m × 15m × 2m | ± 60 Days | Biological treatment |
| Pond 3 | Facultative Pond 2 | 70m × 15m × 2m | ± 60 Days | Biological treatment |
Quality Assurance & Testing
Geosynthetics Africa executed installation to:
Compliance Standards:
-
IAGI Best Practice Installation Guidelines
-
Solmax GSE® Quality Assurance Manual
-
GRI GM13 Specification
Testing Program Completed:
-
Vacuum Box Testing
-
Air Pressure Testing on fusion welds
-
Destructive Shear and Peel weld testing
-
Spark/Holiday Testing for steel tank lining
-
Visual weld mapping & traceability records
Result: Zero defects accepted — full compliance achieved 🔒
Materials Used — Why Performance was Superior
| Product | Supplier | Advantage |
|---|---|---|
| GSE HD HDPE Geomembrane Liners | Geosynthetics Africa | High chemical & biological resistance, virgin material only |
| MIRAFI Liner Protection Geotextiles | Geosynthetics Africa | Best puncture resistance, maintains liner integrity |
| EPDM ,Buffel Liner | Geosynthetics Africa | Flexible and durable sealing of corrugated surfaces |
| Fastening Strips | Geosynthetics Africa | Robust, watertight sealing perimeter |
All products were manufactured in ISO certified factories and have been used at global projects across Africa & Europe.
Community & Economic Impact
-
Local workforce employed
-
Practical geosynthetics installation skills transferred
-
Empowerment aligned with municipal socio-economic goals
Outcome Delivered
✔ Three secure, leak-free treatment ponds
✔ Steel tanks restored to full watertight performance
✔ Increased wastewater treatment capacity
✔ Long-term environmental protection
✔ Compliance with municipal & national water safety standards
✔ Fast delivery under one accountable contractor
