GeoPipe™ - HDPE Drainage Pipe - Corrugated Slotted - 250mm - 6m

R2,000

We supply GeoPipe™ - HDPE Drainage Pipe - Corrugated Slotted - 250mm - 6m. Send us your quantity and delivery location for a quotation, and ask our team to include installation where your project requires it.

GeoPipe DN250 is a slotted corrugated HDPE drainage pipe that collects subsurface water through openings in the pipe wall. It carries the collected water towards a drainage outlet in French drains, road verges, retaining-wall backfill and landscaped areas. Supplied in 6 m lengths.

Request a quote or specification check

Include the product name, quantity and delivery location. Supply, fabrication and installation can be quoted to your scope.

Need help selecting the right grade? View the product selection guide →

SKU: GP250MM Category: Drainage Pipes and Sheets Tags: Africa supplier, agricultural drainage, corrugated HDPE pipe, french drain pipe, HDPE drainage pipe, perforated drainage pipe, retaining wall drainage, road drainage, slotted pipe, South Africa supplier, sports field drainage, subsoil drainage

Description

GeoPipe™ - HDPE Drainage Pipe - Corrugated Slotted - 250mm - 6m is an engineered corrugated HDPE drainage pipe with precision slots to capture and convey subsurface water rapidly. The lightweight yet robust HDPE profile provides high crush resistance, excellent flexibility and long design life in aggressive soils.

Key Advantages

High flow intake - uniform slot geometry promotes rapid water ingress while limiting soil migration.
Crush & impact resistance - corrugated profile withstands traffic loads and ground movement.
Chemical & corrosion resistance - HDPE resists acids, salts and fertilisers; won’t rust or spall.
Smooth internal bore - sustained hydraulic capacity and reduced sediment build - up.
Fast installation - 6m lengths, lightweight handling and easy cutting reduce programme time.

Typical Applications

French drains and subsoil drainage in residential & commercial developments
Road & rail formation drainage; shoulder and median drains
Retaining wall and basement relief drainage
Sports fields, golf courses and parks
Agriculture field drainage and irrigation schemes
Landfill & mine drainage (collection and relief)

Available sizes: 50mm, 75mm, 110mm, 160mm, 200mm, 315mm.

Why Geosynthetics South Africa? We are Africa’s leading supplier of corrugated slotted HDPE drainage pipes - stock on hand, ISO - certified manufacturing, technical selection support, and delivery to sites across South Africa and the continent.

Installation Notes (Best Practice)

Place on a prepared bed of free - draining aggregate; encase with graded stone for rapid inflow.
Use a nonwoven geotextile filter wrap where soils are fine or silty to minimise clogging.
Maintain fall to outlet; connect to inspection points or manholes as required.

Supply, delivery and installation across Africa

Geosynthetics South Africa undertakes projects through three service options:

Supply only - products supplied to the agreed specification.
Supply and delivery - materials and logistics coordinated to your project site.
Supply, delivery and QA/QC-controlled installation - one coordinated scope from procurement to documented handover.

For projects across Africa, we coordinate with the Geosynthetics Africa Group to mobilise installation crews from group companies across the continent. Materials, delivery, mobilisation and project-specific quality records are agreed as part of the project scope.

Discuss your supply or installation project | Explore our product range

Technical Specifications

Dimensions	600 × 25 × 25 cm

Supply, delivery & installation

South African supply

We are the South African supplier of GeoPipe HDPE drainage pipes. We have ready stock of standard grades and formats for South African projects.

Delivery & cross-border supply

We supply GeoPipe HDPE drainage pipes across South Africa and Southern Africa, including cross-border delivery. We coordinate site access, unloading and cross-border documentation for your order.

How we install

We install GeoPipe HDPE drainage pipes. Excavate the trench to line and grade and place the designed bedding and filter arrangement. Lay and join GeoPipe to the required fall, orient slots as specified and connect the outlets. Inspect the line before placing the surrounding drainage material and compacted backfill.

Specialist installation supported by Geosynthetics Africa (Pty) Ltd, an IAGI Installer Member.

Get a supply, delivery & installation quote

Product documents

Ask for the current datasheet and installation instructions for GeoPipe™ - HDPE Drainage Pipe - Corrugated Slotted - 250mm - 6m. Identify the catalogue grade / SKU in your request so the technical submission matches the material quoted.

Technical datasheets · Installation guides

Request documents for this grade

Engineer specification

Supply and install GeoPipe™ - HDPE Drainage Pipe - Corrugated Slotted - 250mm - 6m. Double-wall corrugated slotted HDPE subsoil drainage pipe; exact diameter and length as named; SN8 base pipe, ring stiffness ≥8 kN/m² to ISO 9969; confirm finished slotted configuration to the approved design. Installed by an IAGI Installer Member.

SELECTION · SPECIFICATION · PROJECT SUPPLY

Choose the right specification

Select a complete drainage route from collection through the material to a suitable outlet.

Confirm whether the duty is drainage, leak detection, cable protection or structured-wall conveyance.
Specify dimensions, loading, flow conditions, interfaces and the exact filter arrangement where needed.
Coordinate connections, outlets, access and long-term performance for the actual application.

Define the quality records

Verify product identity, dimensional and relevant mechanical or hydraulic data, connections, filters and damage checks before covering.

For a useful quotation: send the grade or performance specification, quantity, location, required date and scope. Availability, delivery and installation responsibilities are confirmed in the quotation.

Why Geosynthetics South Africa

One enquiry coordinates the specified product, technical submission, delivery and any agreed installation and QA/QC scope. We define quantities, programme, responsibilities and handover requirements against your project.
