GeoCurtain™ Class 1 Silt Curtain - Calm Water Sediment Control

Request a quote

We supply GeoCurtain™ Class 1 Silt Curtain - Calm Water Sediment Control. Send us your quantity and delivery location for a quotation, and ask our team to include installation where your project requires it.

GeoCurtain Class 1 is a floating silt curtain for sediment control during construction in calm ponds, reservoirs and sheltered canals. A suspended skirt forms a barrier that helps limit the spread of disturbed sediment in the water. Configured for calm-water sites.

Request a quote or specification check

Include the product name, quantity and delivery location. Supply, fabrication and installation can be quoted to your scope.

Need help selecting the right grade? View the product selection guide →

Category: Erosion Control Systems Tag: Silt Curtains

Description

Class 1 Silt Curtains for Low-Risk Water Conditions

GeoCurtain™ Class 1 Silt Curtains are designed for low-energy environments with minimal current, wind or wave action, providing effective turbidity control in controlled water bodies.

Typical environments include:

Reservoirs
Pollution control ponds
Canals
Mining return water dams
Construction sediment basins

As per international classification, Class 1 systems are suited to short-term or controlled applications with minimal hydrodynamic loading

Standard Engineering Specification

Floatation: 100mm x 50mm closed cell foam
Skirt: 260gsm nonwoven geotextile
Float chamber: 400gsm UV stabilised PVC
Ballast: 6mm galvanised chain
Connectors:
- Marine-grade zipper skirt connection
- Mechanical float chamber connectors
Anchoring:
- Stainless steel anchoring points

These configurations align with low-risk application design criteria where containment rather than structural resistance is required

Performance Characteristics

High filtration with controlled permeability
Stable vertical deployment in still water
Lightweight and easy to install
Rapid deployment for temporary works

Applications Across Africa

Mining process water ponds
Municipal water treatment ponds
Canal maintenance works
Environmental protection zones
Temporary construction containment

Supply & Installation

Delivered in modular 10m-30m sections
Available for rapid deployment across Africa
Installation support including:
- Anchoring layouts
- Deployment procedures
- Maintenance strategies

Accessories (Full System Supply)

Anchoring systems (shore / bed)
Mooring lines and floats
Connector systems
Ballast chains
Deployment hardware

Supply, delivery and installation across Africa

Geosynthetics South Africa undertakes projects through three service options:

Supply only - products supplied to the agreed specification.
Supply and delivery - materials and logistics coordinated to your project site.
Supply, delivery and QA/QC-controlled installation - one coordinated scope from procurement to documented handover.

For projects across Africa, we coordinate with the Geosynthetics Africa Group to mobilise installation crews from group companies across the continent. Materials, delivery, mobilisation and project-specific quality records are agreed as part of the project scope.

Discuss your supply or installation project | Explore our product range

Supply, delivery & installation

South African supply

We are the South African supplier of GeoCurtain silt curtains. Ready-stock standard options are available, with project-specific fabrication for the sizes and details your works require.

Delivery & cross-border supply

We supply GeoCurtain silt curtains across South Africa and Southern Africa, including cross-border delivery. We coordinate site access, unloading and cross-border documentation for your order.

How we install

We install GeoCurtain silt curtains. Confirm water depth, currents and the approved mooring layout. Connect curtain sections, flotation and ballast, then deploy and anchor the barrier without leaving gaps. Inspect connections and anchors during the works and monitor turbidity where specified.

Specialist installation supported by Geosynthetics Africa (Pty) Ltd, an IAGI Installer Member.

Get a supply, delivery & installation quote

Product documents

Ask for the current datasheet and installation instructions for GeoCurtain™ Class 1 Silt Curtain - Calm Water Sediment Control. Identify the catalogue grade / SKU in your request so the technical submission matches the material quoted.

Technical datasheets · Installation guides

Request documents for this grade

Engineer specification

Supply and install GeoCurtain™ Class 1 Silt Curtain - Calm Water Sediment Control, manufactured by Geosynthetics Africa Group (fabrication). GeoCurtain Class 1; UV-stabilised PVC float chamber 400 g/m²; 260 g/m² geotextile skirt; closed-cell PE flotation. Skirt depth, ballast, flotation and mooring to the approved site-specific design. Installed by an IAGI Installer Member.

SELECTION · SPECIFICATION · PROJECT SUPPLY

Choose the right specification

Choose the system around the solids, water conditions, containment duty and available working space.

For dewatering, provide slurry characteristics, flow and required filtrate quality; representative trials may be needed.
For curtains or containment articles, define flow, depth, exposure, geometry and anchorage or filling conditions.
Confirm fabric, dimensions, seams, connections, handling and operating limits for the actual system.

Define the quality records

Retain material and fabrication records, inspect deployment and connections, and agree operating inspections and acceptance criteria.

For a useful quotation: send the grade or performance specification, quantity, location, required date and scope. Availability, delivery and installation responsibilities are confirmed in the quotation.

Why Geosynthetics South Africa

One enquiry coordinates the specified product, technical submission, delivery and any agreed installation and QA/QC scope. We define quantities, programme, responsibilities and handover requirements against your project.
